ESD POM plastic granules for anti static products
Name |
Chinese factory ESD POM plastic granules for electronic products |
Model |
646A-22-JC |
Usage |
Injection and Extrusion level |
Color |
Nature Color or customized |
Filler |
ESD agent&POM materials |
Application |
ESD sheet,board,roll etc. |
Brand |
Ansuyi |
Oringin From |
Guangdong,China |
Contacting way |
yvonneyao@ansuyi.com |
What is ESD POM plastic materials?
ESD Polyoxymethylene from Ansuyi is an engineering plastic with excellent anti static properties and high mechanical strength. It is widely used in extrusion and injection applications such as the parts of automobiles and medical equipment.Some key features and benefits of ESD POM plastic granules include:
- Excellent ESD properties: ESD Polyoxymethylene plastic granules effectively dissipate static charges.The surface resistance is 10^8-10^9 ohms
- High performance: ESD POM is a high-performance engineering plastic that offers exceptional strength, stiffness, and dimensional stability.
- Easy processing: ESD POM plastic granules can be easily processed and the density is 1.50 g/cm3
- It does not contain colorants or harmful dyes and meets requirements of REACH.
Why choose our ESD POM plastic materials
1. Firstly, our ESD POM plastic materials are fully customizable, we can manufacture them in any color you need such as green, purple, red, yellow, white and so on.
2. Secondly, Ansuyi ESD POM has already successfully used in the medical equipment , automobile packaging. On one hand, we ensure the quality of our ESD POM materials, on the other hand,we can massively produce the materials to save the cost of our clients. So that the POM ESD materials are more competitive in the market.
[Basic physical properties table] Permanent anti-static POM 646A-22-JC |
||||
POM |
Specification level |
Appearance color |
Note instructions |
|
General grade |
true qualities |
Mainly used for electronic products shell and other anti-static injection molding products, high strength, stable toilet surface resistance, easy to shape, high wear resistance |
||
Feature |
test method |
test condition |
unit |
test data |
Density |
ISO 1183 |
g/cm3 |
1.50 |
|
Forming shrinkage rate |
ISO294-4 |
% |
0.4〜0.7 |
|
Tensile strength |
ISO 527 |
MPa |
90 |
|
Bending strength |
ISO178 |
Mpa |
133 |
|
Lipid dissolution index |
ISO 1133 |
240℃/5kg |
g/10min |
9 |
Yield stress |
ISO 527 |
Mpa |
50 |
|
Surface resistivity |
ISO3915-1981 |
Ω |
108 |
|
IZOD notch impact strength |
ISO179-1 |
23℃ /6.4mm |
J/m |
9 |
Distortion temperature |
ISO 75 |
1.80MPa |
℃ |
118 |
The drying temperature |
ISO 75 |
℃ |
Drying material for 3-4 hours, temperature: 85℃ |
|
Injection temperature |
ISO 75 |
℃ |
180℃~210℃ |
